3.5 Power Cables and Encoder Extension Cables
See also 2.7.1 MOTOR POWER CABLES and 2.7.2 ENCODER EXTENSION CABLES in
the ‘man_bcs3d_ec_user.pdf’ manual.
There are the following motor/drive power cables and encoder extension cables:
MOTOR POWER CABLES ENCODER CABLES SERVOMOTOR  SERVO DRIVE
MPC-FBM3J-N9718-03
EEC-FBM3J-A1724-03
FBM3J-02ALA
 22 
FBM3J-04ALA
 22 
BCS3D-02AEA-FS02
BCS3D-04AEA-FS02
MPC-FBM3J-N9718-05
EEC-FBM3J-A1724-05
MPC-FBM3J-N9718-08
EEC-FBM3J-A1724-08
MPC-FBM3J-N9718-10
EEC-FBM3J-A1724-10
MPC-FBM3J-N9718-15
EEC-FBM3J-A1724-15
MPC-FBM3J-N9718-20
EEC-FBM3J-A1724-20
MPC-FBM3J-B9718-03
EEC-FBM3J-A1724-03
FBM3J-02ALA
 42 
FBM3J-04ALA
 42 
BCS3D-02AEA-FS02
BCS3D-04AEA-FS02
MPC-FBM3J-B9718-05
EEC-FBM3J-A1724-05
MPC-FBM3J-B9718-08
EEC-FBM3J-A1724-08
MPC-FBM3J-B9718-10
EEC-FBM3J-A1724-10
MPC-FBM3J-B9718-15
EEC-FBM3J-A1724-15
MPC-FBM3J-B9718-20
EEC-FBM3J-A1724-20
MPC-FBM3J-N8718-03
EEC-FBM3J-A1724-03
FBM3J-08ALA
 22 
FBM3J-10ALA
 22 
BCS3D-08AEA-FS02
BCS3D-10AEA-FS02
MPC-FBM3J-N8718-05
EEC-FBM3J-A1724-05
MPC-FBM3J-N8718-08
EEC-FBM3J-A1724-08
MPC-FBM3J-N8718-10
EEC-FBM3J-A1724-10
MPC-FBM3J-N8718-15
EEC-FBM3J-A1724-15
MPC-FBM3J-N8718-20
EEC-FBM3J-A1724-20
MPC-FBM3J-B8718-03 EEC-FBM3J-A1724-03
FBM3J-08ALA
 42 
FBM3J-10ALA
 42 
BCS3D-08AEA-FS02
BCS3D-10AEA-FS02
MPC-FBM3J-B8718-05 EEC-FBM3J-A1724-05
MPC-FBM3J-B8718-08 EEC-FBM3J-A1724-08
MPC-FBM3J-B8718-10 EEC-FBM3J-A1724-10
MPC-FBM3J-B8718-15 EEC-FBM3J-A1724-15
MPC-FBM3J-B8718-20 EEC-FBM3J-A1724-20
MPC-FBM3G-N9314-03 EEC-FBM3G-A1924-03
FBM3G-09ALA
 24 
FBM3G-13ALA
 24 
FBM3G-18ALA
 24 
BCS3D-10AEA-FS02
BCS3D-15AEA-FS02
BCS3D-20AEA-FS02
MPC-FBM3G-N9314-05
EEC-FBM3G-A1924-05
MPC-FBM3G-N9314-08
EEC-FBM3G-A1924-08
MPC-FBM3G-N9314-10
EEC-FBM3G-A1924-10
MPC-FBM3G-N9314-15
EEC-FBM3G-A1924-15
MPC-FBM3G-N9314-20
EEC-FBM3G-A1924-20
MPC-FBM3G-B9314-03
EEC-FBM3G-A1924-03
FBM3G-09ALA
 44 
FBM3G-13ALA
 44 
FBM3G-18ALA
 44 
BCS3D-10AEA-FS02
BCS3D-15AEA-FS02
BCS3D-20AEA-FS02
MPC-FBM3G-B9314-05
EEC-FBM3G-A1924-05
MPC-FBM3G-B9314-08
EEC-FBM3G-A1924-08
MPC-FBM3G-B9314-10
EEC-FBM3G-A1924-10
MPC-FBM3G-B9314-15
EEC-FBM3G-A1924-15
MPC-FBM3G-B9314-20
EEC-FBM3G-A1924-20
