16|52 - BCS3D EtherCAT Beta EtherCAT Servo 3 Drive series | Ref.2403
Installation Manual
Medium inertia 5.50 kW feed axis motors
Medium inertia 7.50 kW feed axis motors
MOTOR MODEL SERVO DRIVE MODEL MEDIUM INERTIA. 400 Vac
FBM3G-55DLA124 BCS3D-75DEA-FS02
FAGOR axis motor, 400 Vac, 5.50 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end keyless, with oil seal, brakeless and
aviation plug type.
FBM3G-55DLA224 BCS3D-75DEA-FS02
FAGOR axis motor, 400 Vac, 5.50 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end with key, with oil seal, brakeless and
aviation plug type.
FBM3G-55DLA144 BCS3D-75DEA-FS02
FAGOR axis motor, 400 Vac, 5.50 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end keyless, with oil seal, with holding
brake and aviation plug type.
FBM3G-55DLA244 BCS3D-75DEA-FS02
FAGOR axis motor, 400 Vac, 5.50 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end with key, with oil seal, with holding
brake and aviation plug type.
MOTOR MODEL MOTOR POWER CABLE ENCODER CABLE  LENGTH (m)
FBM3G-55DLA
 24 MPC-FBM3G-N9212- EEC-FBM3G-A1924- 03, 05, 08, 10, 15, 20
FBM3G-55DLA
 44 MPC-FBM3G-B9212-
EEC-FBM3G-A1924-
03, 05, 08, 10, 15, 20
MOTOR MODEL SERVO DRIVE MODEL MEDIUM INERTIA. 400 Vac
FBM3G-75DLA124 BCS3D-75DEA-FS02
FAGOR axis motor, 400 Vac, 7.50 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end keyless, with oil seal, brakeless and
aviation plug type.
FBM3G-75DLA224 BCS3D-75DEA-FS02
FAGOR axis motor, 400 Vac, 7.50 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end with key, with oil seal, brakeless and
aviation plug type.
FBM3G-75DLA144 BCS3D-75DEA-FS02
FAGOR axis motor, 400 Vac, 7.50 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end keyless, with oil seal, with holding
brake and aviation plug type.
FBM3G-75DLA244 BCS3D-75DEA-FS02
FAGOR axis motor, 400 Vac, 7.50 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end with key, with oil seal, with holding
brake and aviation plug type.
MOTOR MODEL MOTOR POWER CABLE ENCODER CABLE  LENGTH (m)
FBM3G-75DLA
 24 MPC-FBM3G-N9211- EEC-FBM3G-A1924- 03, 05, 08, 10, 15, 20
FBM3G-75DLA
 44 MPC-FBM3G-B9211- EEC-FBM3G-A1924- 03, 05, 08, 10, 15, 20
