Medium inertia 2.90 kW feed axis motors
Medium inertia 4.40 kW feed axis motors
MOTOR MODEL SERVO DRIVE MODEL MEDIUM INERTIA. 400 Vac
FBM3G-29DLA124 BCS3D-30DEA-FS02
FAGOR axis motor, 400 Vac, 2.90 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end keyless, with oil seal, brakeless and
aviation plug type.
FBM3G-29DLA224 BCS3D-30DEA-FS02
FAGOR axis motor, 400 Vac, 2.90 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end with key, with oil seal, brakeless and
aviation plug type.
FBM3G-29DLA144 BCS3D-30DEA-FS02
FAGOR axis motor, 400 Vac, 2.90 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end keyless, with oil seal, with holding
brake and aviation plug type.
FBM3G-29DLA244 BCS3D-30DEA-FS02
FAGOR axis motor, 400 Vac, 2.90 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end with key, with oil seal, with holding
brake and aviation plug type.
MOTOR MODEL MOTOR POWER CABLE ENCODER CABLE  LENGTH (m)
FBM3G-29DLA
 24 MPC-FBM3G-N8214- EEC-FBM3G-A1924- 03, 05, 08, 10, 15, 20
FBM3G-29DLA
 44 MPC-FBM3G-B8214-
EEC-FBM3G-A1924-
03, 05, 08, 10, 15, 20
MOTOR MODEL SERVO DRIVE MODEL MEDIUM INERTIA. 400 Vac
FBM3G-44DLA124 BCS3D-50DEA-FS02
FAGOR axis motor, 400 Vac, 4.40 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end keyless, with oil seal, brakeless and
aviation plug type.
FBM3G-44DLA224 BCS3D-50DEA-FS02
FAGOR axis motor, 400 Vac, 4.40 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end with key, with oil seal, brakeless and
aviation plug type.
FBM3G-44DLA144 BCS3D-50DEA-FS02
FAGOR axis motor, 400 Vac, 4.40 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end keyless, with oil seal, with holding
brake and aviation plug type.
FBM3G-44DLA244 BCS3D-50DEA-FS02
FAGOR axis motor, 400 Vac, 4.40 kW,
23-bit absolute serial encoder, 8388608 P/R,
Shaft end with key, with oil seal, with holding
brake and aviation plug type.
MOTOR MODEL MOTOR POWER CABLE ENCODER CABLE  LENGTH (m)
FBM3G-44DLA
 24 MPC-FBM3G-N9212- EEC-FBM3G-A1924- 03, 05, 08, 10, 15, 20
FBM3G-44DLA
 44 MPC-FBM3G-B9212-
EEC-FBM3G-A1924-
03, 05, 08, 10, 15, 20
