EXAMPLE MANUAL 49
Part 4: "Shows the consumption of motors"
The speed drives have an analog output (0 to 10V) proportional to the current consumed by the motor.
In this example, the following connections have been made:
- The X axis drive’s current output is connected to the analog input 1 of the CNC.
- The Z axis drive’s current output is connected to the analog input 2 of the CNC.
- The spindle (S) drive’s current output is connected to the analog input 3 of the CNC.
Therefore, variables "ANAI1”, “ANAI2” and “ANAI3” show the analog voltage corresponding to the currents of the
X and Z axes and of the spindle S.
21 symbols (0-20) are used to display the value of the current, in increments corresponding to 0.5V.
To select the right symbol each time, the formula: "ABS ROUND (ANAI1/0.5)" is applied. In other words, the
rounded-up absolute value of the result of the operation "ANAI1/0.5".
Program lines.
N400 (PAGE 4) ......................................... Shows page 4.
(KEY = 0) ....................................... Clears memory of last key pressed.
N410 (SYMBOL ABS ROUND (ANAI1/0.5), 130, 120)
(SYMBOL ABS ROUND (ANAI2/0.5), 130, 190)
(SYMBOL ABS ROUND (ANAI3/0.5), 130, 260)
(IF KEY EQ $FFA5 GOTO N300) ... If "previous page" has been pressed, it goes on to line N300
(part 3)
(GOTO N410) ................................... If not, it refreshes the motor consumption.
Editing symbols 0-20
Access the screen customizing mode and select: [Utilities] [Editor] [Symbol] (symbol number) [Enter]
FILLED RECTANGLE FINE SOLID LINE
Green Yellow Red Gray Green Yellow Red
From to From to From to From to From to From to From to
SYMBOL 0 --- --- --- --- --- --- X0 Y0 X400 Y30 X100 Y0 X100 Y30 X200 Y0 X200 Y30 X300 Y0 X300 Y30
SYMBOL 1 X0 Y0 X20 Y30 --- --- --- --- X20 Y0 X400 Y30 X100 Y0 X100 Y30 X200 Y0 X200 Y30 X300 Y0 X300 Y30
SYMBOL 2 X0 Y0 X40 Y30 --- --- --- --- X40 Y0 X400 Y30 X100 Y0 X100 Y30 X200 Y0 X200 Y30 X300 Y0 X300 Y30
SYMBOL 3 X0 Y0 X60 Y30 --- --- --- --- X60 Y0 X400 Y30 X100 Y0 X100 Y30 X200 Y0 X200 Y30 X300 Y0 X300 Y30
SYMBOL 4 X0 Y0 X80 Y30 --- --- --- --- X80 Y0 X400 Y30 X100 Y0 X100 Y30 X200 Y0 X200 Y30 X300 Y0 X300 Y30
SYMBOL 5 X0 Y0 X100 Y30 --- --- --- --- X100 Y0 X400 Y30 --- --- X200 Y0 X200 Y30 X300 Y0 X300 Y30
SYMBOL 6 X0 Y0 X120 Y30 --- --- --- --- X120 Y0 X400 Y30 --- --- X200 Y0 X200 Y30 X300 Y0 X300 Y30
SYMBOL 7 X0 Y0 X140 Y30 --- --- --- --- X140 Y0 X400 Y30 --- --- X200 Y0 X200 Y30 X300 Y0 X300 Y30
SYMBOL 8 X0 Y0 X160 Y30 --- --- --- --- X160 Y0 X400 Y30 --- --- X200 Y0 X200 Y30 X300 Y0 X300 Y30
SYMBOL 9 X0 Y0 X180 Y30 --- --- --- --- X180 Y0 X400 Y30 --- --- X200 Y0 X200 Y30 X300 Y0 X300 Y30
SYMBOL 10 X0 Y0 X200 Y30 --- --- --- --- X200 Y0 X400 Y30 --- --- --- --- X300 Y0 X300 Y30
SYMBOL 11 X0 Y0 X200 Y30 X200 Y0 X220 Y30 --- --- X220 Y0 X400 Y30 --- --- --- --- X300 Y0 X300 Y30
SYMBOL 12 X0 Y0 X200 Y30 X200 Y0 X240 Y30 --- --- X240 Y0 X400 Y30 --- --- --- --- X300 Y0 X300 Y30
SYMBOL 13 X0 Y0 X200 Y30 X200 Y0 X260 Y30 --- --- X260 Y0 X400 Y30 --- --- --- --- X300 Y0 X300 Y30
SYMBOL 14 X0 Y0 X200 Y30 X200 Y0 X280 Y30 --- --- X280 Y0 X400 Y30 --- --- --- --- X300 Y0 X300 Y30
SYMBOL 15 X0 Y0 X200 Y30 X200 Y0 X300 Y30 --- --- X300 Y0 X400 Y30 --- --- --- --- --- ---
SYMBOL 16 X0 Y0 X200 Y30 X200 Y0 X300 Y30 X300 Y0 X320 Y30 X320 Y0 X400 Y30 --- --- --- --- --- ---
SYMBOL 17 X0 Y0 X200 Y30 X200 Y0 X300 Y30 X300 Y0 X340 Y30 X340 Y0 X400 Y30 --- --- --- --- --- ---
SYMBOL 18 X0 Y0 X200 Y30 X200 Y0 X300 Y30 X300 Y0 X360 Y30 X360 Y0 X400 Y30 --- --- --- --- --- ---
SYMBOL 19 X0 Y0 X200 Y30 X200 Y0 X300 Y30 X300 Y0 X380 Y30 X380 Y0 X400 Y30 --- --- --- --- --- ---
SYMBOL 20 X0 Y0 X200 Y30 X200 Y0 X300 Y30 X300 Y0 X400 Y30 --- --- --- --- --- --- --- ---
