AUXILIARY MODULES
External Ballast resistors
200
Ref.1912
DDS
HARDWARE
· 190 ·
Use the attached table to select the Ballast resistor for your compact drive
when applicable with enough rms power to dissipate the energy generated
while braking.
MAIN POWER
SUPPLY
OHM RMS
POWER
RESISTOR
MODEL
XPS-65
9 
1.9 kW 2x ER+TH-18/1100 in parallel
2.6 kW 2x ER+TH-18/1800 in parallel
4.0 kW 2x R+TH-18/2200 in parallel
4.0 kW 2x ER+TH-18/1000+FAN in parallel
6.0 kW 2x ER+TH-18/1500+FAN in parallel
8.0 kW 2x ER+TH-18/2000+FAN in parallel
T. H4/10 Possible braking resistors to be installed on compact drives.
Required Ohm values.
DRIVE OHM RMS
POWER
RESISTOR
MODEL
ACD 1.15 43  300 W Internal R.
CMC 1.15 43  300 W Internal R.
SCD 1.15 43  300 W
Internal R. or external ER+TH-43/350
(with external thermostat)
ACD 1.25
24  250 W 24550 W *
CMC 1.25
24  250 W 24550 W *
SCD 1.25
24  650 W 24 750 W * with external thermostat
SCD 1.25...NR 24  950 W ER+TH-24/1100
ACD 2.35 18  450 W 18900 W *
CMC 2.35 18  450 W 18900 W *
SCD 2.35 18  1.3 kW 18 1800 W * with internal thermostat
SCD 2.35...NR 18 
2.0 kW ER+TH-18/2200
2.0 kW ER+TH-18/1000+FAN
3.0 kW ER+TH-18/1500+FAN
4.0 kW ER+TH-18/2000+FAN
ACD 2.50
18  450 W 18900 W *
CMC 2.50
18  450 W 18 900W *
SCD 2.50
18  1.3 kW 18 1800 W * with internal thermostat
SCD 2.50...NR 18 
2.0 kW ER+TH-18/2200
2.0 kW ER+TH-18/1000+FAN
3.0 kW ER+TH-18/1500+FAN
4.0 kW ER+TH-18/2000+FAN
SCD 2.75 18  3.0 kW ER+TH-18/1500+FAN *
SCD 2.75...NR 18  4.0 kW ER+TH-18/2000+FAN
* FAGOR supplies the resistors indicated with an asterisk (see shaded rows) as
accessories with the unit. The rest of them are supplied only upon request.
T. H4/9 Possible braking resistors to be installed on power supplies.
Required Ohm values.
