Page #32 background imageLoading...
Page #32 background image
Description
1.
32
Ref.1912
DDS
HARDWARE
· 32 ·
1.5 Environmental conditions
1.6 Electrical conditions
Conditions Standard Test reference
Mechanical specifications
Transport
Vibration Acc. to
IEC 60721-3-2
Class 2M1, vibration sinusoidal
2 Hz < f 9 Hz, 3.5 mm amplitude
9 Hz < f 200 Hz, 1 g
200 Hz < f 500 Hz, 1.5 g
Shock limits Acc. to
IEC 60721-3-2
IEC 61800-2
Class 2M1,
equipment in its
transport package
Operation
Environmental
testing-vibration
(sinusoidal)
Acc. to
IEC 60068-2-6
Test Fc
Vibration sinusoidal
10 Hz < f 57 Hz,
0.075 mm constant amplitude
57 Hz < f 150 Hz,
1 g constant acceleration
Degrees of protection
provided by enclosure
(IP code)
Acc. to
EN 60529
IP 2x.
It should be installed
inside of an electrical cabinet.
Climatic conditions
Storage *
Ambient
temperature
Acc. to
IEC 60721-3-1
IEC 61800-2
1K4,
-25 ºC to + 60 ºC
Transport *
Damp heat test
(steady state)
Acc. to
IEC 60068-2-78
IEC 61800-5-1
Power Supply disconnected
40 ºC +/-2 ºC and
93 % +2-3 % non-condensing
Ambient
temperature
Acc. to
IEC 61800-2
Equipment introduced in
its shipping package
-25 ºC to +70 ºC
Operation
Environmental
testing-cold
Acc. to
IEC 60068-2-1,+
0 ºC at
operating conditions
Environmental
testing-dry heat
Acc. to
IEC 60068-2-2
Test Bd
Operating at rated conditions
45 ºC.
Operating conditions between
0 ºC and 60 ºC with derating
· see derating characteristics ·
Damp heat test
(steady state)
Acc. to
IEC 60068-2-78
IEC61800-5-1
Power supply disconnected
40 ºC +/-2 ºC and
93 % +2-3 % non-condensing
Installation altitude
above mean sea
level without derating
Acc. to
IEC 61800-5-1
IEC 60664-1
Pollution degree 2 and
altitude < 2000 m above sea
level at rated conditions
* The environment during transport and storage must be dry and free from dust.
Electrical conditions
Acc. to
IEC 61800-5-1
Protection class Class I
(with protective conductor system)
Acc. to
IEC 60664-1
Mains overvoltages Category III
