7.3 Motor feedback cables
The attached tables show the range of motor encoder cables supplied by
FAGOR to connect the motor feedback and a drive. They are supplied with
connectors at both ends (see note below) and their sales model is:
With FXM/FKM motors
EEC-SP-  cable
For further detail on how to connect the drive, see the manual of the
corresponding motor.
IECD-  cable
For further detail on how to connect the drive, see the manual of the
corresponding motor.
With FM7 motors
EEC-FM7-  cable
For further detail on how to connect the drive, see the manual of the
corresponding motor.
EEC-FM7S-  cable
For further detail on how to connect the drive, see the manual of the
corresponding motor.
Motor Ref. Cable Motor feedback
FXM, FKM
EEC-SP-
 1 Vpp sinusoidal encoder
IECD-
 Incremental TTL encoder
FM7
EEC-FM7-
 Incremental TTL encoder
EEC-FM7S-

Incremental TTL encoder
(better immunity and flexibility)
EEC-FM7CS-
 C axis SinCos encoder
Note. None of the motor encoder feedback cables for FM7 spindle motors
will have the connector mounted at the motor end; a connector will be
supplied with the cable for the user to mount it. See the manual: AC spindle
motor - FM7/FM9 - for further detail on how to mount it.
INFORMATION. The encoder cable (without connectors) is only available
upon request in lengths of 75, 100 and150 m.
i
T. H7/8 Range of EEC-SP- cables. The number indicates their length in
meters including the connectors.
EEC-SP-3 EEC-SP-5 EEC-SP-6 EEC-SP-7 EEC-SP-8
EEC-SP-9 EEC-SP-10 EEC-SP-11 EEC-SP-12 EEC-SP-15
EEC-SP-20 EEC-SP-25 EEC-SP-30 EEC-SP-35 EEC-SP-40
EEC-SP-45 EEC-SP-50 EEC-SP-60
INFORMATION. Remember that using the cable model EEC-SP- does
guarantee compliance with the Directive on Electromagnetic Compatibility
2014/30/EU.
i
T. H7/9 Range of IECD- cables.The number indicates their length in
meters including the connectors.
IECD-5 IECD-7 IECD-10 IECD-15 IECD-20 IECD-25 IECD-30
T. H7/10 Range of EEC-FM7- cables. The number indicates their length in
meters including the connector.
EEC-FM7-5 EEC-FM7-10 EEC-FM7-15 EEC-FM7-20 EEC-FM7-25
T. H7/11 Range of EEC-FM7S- cables. The number indicates their length
in meters including the connector.
EEC-FM7S-3 EEC-FM7S-15 EEC-FM7S-30 EEC-FM7S-45
EEC-FM7S-05 EEC-FM7S-20 EEC-FM7S-35 EEC-FM7S-50
EEC-FM7S-10 EEC-FM7S-25 EEC-FM7S-40 EEC-FM7S-60
