Fagor DDS Series - External Thermostat

Dimensions
11.
DIMENSIONS
External Ballast resistors with external thermostat & cooling fan
384
Ref.1912
DDS
HARDWARE
· 384 ·
11.11 External Ballast resistors with external thermostat & cooling fan
11.12 External thermostat
F. H11/26
External Ballast resistors with external thermostat and fan. Dimensions.
F. H11/27
External thermostat. Dimensions.
ER+TH-
18/2000+FAN
in
6.88
6.49
2.99
6.06
20.86
19.68
9.84
21.57
2.55
mm
175
165
76
154
530
500
250
548
6.5
ER+TH-
18/1500+FAN
in
6.88
6.49
2.99
6.06
12.95
11.02
9.84
13.66
2.55
mm
175
165
76
154
329
280
250
347
6.5
ER+TH-
18/1000+FAN
in
6.88
6.49
2.99
6.06
6.69
4.76
9.84
7.40
2.55
mm
175
165
76
154
170
121
250
188
6.5
With external
thermsotat
Units
B1
B2
H1
H2
L1
L2
L3
L
ØD
H1
B1

119
H2
L
B2
L2
4-ØD
L1
L3
Dimensions in mm. 1 in = 25.4 mm
