Power line connection
6.
238
Ref.1912
DDS
HARDWARE
· 228 ·
The fuse references given of the previous table are the ones that may be
installed to obtain the maximum power on each model. In those cases where
the power supply is oversized, the fuse value should be adjusted to the
actual requirements of the machine.
T. H6/3 Fuses to be installed in mains line depending on the power supply
installed.
MANUFACTURER
PS-25B4
XPS-25
RPS-20
PS-65A
XPS-65
RPS-45
RPS-75
RPS-80
BUSMANN
FWH45B RF00-125A -
XL50F-45A XL50F-125A -
RF-000-40A RF-000-125A -
40FE 100FE 160FE
170M2611 170M1318 170M1319
170M3009 170M3013 170M3014
GOULD
A00-66C5D8 A00-66C125D8 -
A00-66C5D1 A00-66C125D1 -
FERRAZ
6.9 gRB 00
D08L 040
6.9 gRB 00
D08L 125
6.9 gRB 00
D08L 160
6.6 gRB 000
D08/040
6.6 gRB 000
D08/100
6.6 gRB 000
D08/160
SIBA 20 189 20-50A 20 189 20-125A 20 189 20-160A
WICKMAN 45FEE 140FEE -
SIEMENS
3NE8 003 3NE8 021 3NC8423-3
LITTELFUSE - L70S125 L70S150
T. H6/4 Fuses to be installed in mains line depending on the compact drive
installed.
ACD/SCD/CMC SCD
MANUFACTURER
1.08 1.15 1.25 2.35/50 2.75
BUSSMANN
FC-6A FC-12A FC-20A FWC-32A10F -
XL50-10A XL50-15A RF-000-25 FWP-32A14F -
6CT 12CT - - -
FWH-6.30A6F - - - -
GOULD
ST-6
10x38
ST-12
10x38
ST-20
10x38
--
000-10 000-16 A60x20 - -
000/80-10 000/80-16 - - -
FERRAZ
6.600CP URC
14.51/6
12.600CP URC
14.51/6
--
6.921CP URQ
27x60/63
6.621CP URC
14.51/6
12.621CP URC
14.51/6
-- -
6.6URE10/6 12.6URE10/6 - - -
A60Q6-2 A60Q12-2 A60Q20-2 A60Q30-2 -
A60X6-1 A60X12-1 - - -
SIBA
----
50-140-34.63
without striker
----
50 142 34.63
with striker
SIEMENS
- - 3NE8 015 3NE8 003 -
WARNING. Using other protection devices instead of fuses (magneto-
thermal switches, for example) does no guarantee proper protection of the
equipment.
MANDATORY. When using an auto-transformer or an isolating transformer,
the fuses must be selected according to its characteristics depending on the
structure of the installation. Therefore, the fuses must be selected
specifically for each installation since it will be affected by a variable number
of characteristics internal and external to the machine.
