DDS
HARDWARE
CABLES
This chapter describes the cables needed to install the DDS system and
the characteristics of the connectors of those cables. It also describes the
mechanical characteristics of those cables.
Previous chapters of this manual already described the cabling of the DDS
system for the power lines, feedback, optic fiber of the SERCOS ring or
CAN BUS connection, RS-232/422 serial line connection, communications
etc.
MANDATORY. The length of any cable used in the installation of the DDS
system must be shorter than 30 m, except for the power (motor), feedback
(encoder), fiber optic cables (SERCOS interface) and CAN bus cables,
which may exceed this length.
