Fagor DDS Series User Manual

Dimensions
11.
DIMENSIONS
Bus Protection Module, BPM
384
Ref.1912
DDS
HARDWARE
· 378 ·
11.4 Bus Protection Module, BPM
11.5 Capacitor Module, CM-1.75
F. H11/19
B
us Protection Module, BPM. Dimensions.
F. H11/20
C
apacitor Module, CM-1.75. Dimensions.
R3.5
8.5
22
R3.5
R6.5
8
7.5
77
266
373
45
255
389
347
Dimensions in mm. 1 in = 25.4 mm
CAPACITOR MODULE
A
A
R3.5
8.5
22
R3.5
R6.5
8
7.5
263.5
77
373
255
389
347
Dimensions in mm. 1 in = 25.4 mm
