DDS
HARDWARE
12.6 Power supplies
F. H12 /11
Non-regenerative power supplies, PS. Denominations.
F. H12/12
Regenerative power supplies, XPS. Denominations.
F. H12/13
Regenerative regulated power supplies, RPS. Denominations.
Example:
POWER
(po , c )wer rated urrent
65A (65 kW, 120 A)
P SOWER UPPLY (mains voltage of 400/460 V AC)
NON REGENERATIVE
POWER SUPPLY, PS
PS-65A
Example:
POWER
(power, rated current)
auxiliary power supply (voltage, current) (24 V DC, 10 A)
P SOWER UPPLY (mains voltage of 400/460 V AC)
POWER SUPPLY WITH INTEGRATED
AUXILIARY 24 V POWER SUPPLY, PS
PS-25B4-C
25B4 (25 kW, 45 A)
SPECIAL
C
for industrial environments with graphite
CONFIGURATION
None
standard
Example:
POWER
(power, rated current)
65 (65 kW, 120 A)
X- P SCIRCUIT OWER UPPLY (mains voltage of 400/460 V AC)
REGENERATIVE
POWER SUPPLY, XPS
XPS-25
25 (25 kW, 45 A)
Example:
POWER
(power S1/S6-40%,
current IS1/IS6-40%)
75 (75/97 kW, 120/156 A)
RP SEGENERATIVE OWER UPPLY (mains voltage of 400/460 V AC)
REGENERATIVE BOOST
POWER SUPPLY, RPS
RPS-20-C
45 (45/59 kW, 72/95 A)
20 (20/26 kW, 32/41.6 A)
80 (80/104 kW, 128/166.5 A)
SPECIAL
C
for industrial environments with graphite *
CONFIGURATION
-
standard
* only available on RPS-20 model
