Fagor DDS Series User Manual

13
Ref.1912
· 399 ·
DDS
HARDWARE
COMPATIBILITY
13.1 Mains voltage
Originally, the drives and power supplies were designed for a line voltage of
380 V AC (50/60 Hz). They all have been now redesigned to work with line
voltage ranging between 400/460 V AC (50/60 Hz).
Their identification comes on the label that each of these module has.
The catalog will later include the ACD/SCD compact drives that can also
be connected to the mains with line voltages in the range of 200/240 V
AC and 50/60 Hz.
13.2 Compatibility
The elements ready for mains voltage between 400/460 V AC:
 Drive (version MSC 12A and later).
 Auxiliary power supply APS-24 (version PF 05A and later).
 Capacitor module CM-60 (version 01A and later) or CM-1.60 (version
[CAP 00A] [VAR 02A] and later) replacing the previous one.
 Mains filters ·EMK· or ·MAIN FILTER· compatible with all power
supplies PS, XPS and RPS.
The elements ready for mains voltage between 380 V AC:
 Drive (version MSC 11A and older).
 Auxiliary power supply APS-24 (version PF 04A and older).
 Capacitor module CM-60 (version 00A and later) or CM-1.60 (version
[CAP 00A] [VAR 02A] and later) replacing the previous one.
 Mains filters ·POWER-PRO· are not compatible with power supplies
PS-
A, PS-25B, XPS and RPS.
F. H13 /1
Module identification labels. Range of operating line voltages.
PS-25MODEL
INPUT
OUTPUT
Fagor Automation,
S.Coop.(Spain)
600 Vdc 45A
3x380 Vac 50/60Hz
MODEL
INPUT
OUTPUT
Fagor Automation S.Coop.
San Andres Auzoa 19
20500 Arrasate-Mondragón
SPAIN
AXD 1.15-A1-1MODEL
INPUT
OUTPUT
Fagor Automation,
S.Coop.(Spain)
3x380 Vac 7A 0-800Hz
600-800 Vdc
380 V AC
Power suppliesDrives
400- 460 V AC
3x400-460 VAC 50-60 Hz
565-650 VDC 45A
PS-25 B4
MODEL
INPUT
OUTPUT
Fagor Automation S.Coop.
San Andres Auzoa 19
20500 Arrasate-Mondragón
SPAIN
456-800 VDC
3x0-460 VAC 7.5A 0-550 Hz
AXD 1.15-A1-1
