Drives
3.
Ref.1912
· 99 ·
DDS
HARDWARE
T. H3/5 Modular drives. Technical data.
AXD|SPD|MMC
1.08 1.15 1.25 1.35 2.50 2.75 2.85 3.100
3.150
3.200
3.250
Power voltage input 542/800 V DC
Power to control circuits 24 V DC (between 21 V DC and 28 V DC)
Consumption of the control
circuits (24 V DC)
0.90 A 1.25 A 2.00 A
Speed feedback Encoder
Controlling method PWM, AC sinewave, vector control
Communication Serial line to connect to a PC
Interface
Standard analog, digital SERCOS-II ring (in all models)
CAN bus (in all models).
Serial line RS-232/422 (only in MMC drives)
Status display 7-segment display
Protections
Over-voltage, over-current, over-speed, heat-sink temperature,
CPU temperature, motor temperature, hardware error, overload.
Frequency
·1·
0-550 Hz
Speed range with analog input 1:8192
Current bandwidth 800 Hz
Speed bandwidth 100 Hz (depends on the motor/drive set)
Ambient temperature
·2·
0°C/45°C (32°F/113°F)
Maximum working temperature limit: 60°C/140°F
Storage temperature -25°C/60°C (-13°F/140°F)
Sealing IP 2x
Maximum humidity < 90 % (non condensing at 45°C/113°F)
Maximum installation altitude
2 000 m (6 561 ft) above sea level
Operating vibration 1 g
Shipping vibration
1.5 g
Approx. mass in kg
lb
5.5
12.1
5.5
12.1
6.0
13.2
6.5
14.3
9.0
19.8
9.0
19.8
10.0
22.0
14.0
30.8
19.5
43.0
·1·
Higher than 550 Hz only for commercial models
SPD ... - MDU
(dual-use).
·2·
For high temperatures, refer to derating graphs ·power reduction graph·.
