11ENDURANCE 50F MOBILE HOME AND STOVE INSTALLATION
Optional
Diffuser
CS1-7100
converts the 50F
bio-mass furnace
into a stand-
alone stove.
Mobile Home Installation
Installation as a Stove
1. Permanently bolt the furnace to the floor.
2. Electrically ground the furnace and pedestal to the metal
chassis of the home. Use a number eight (8) gauge or larger
copper wire.
3. Maintain an effective vapor barrier at location where PL
vent exits the structure.
4. Check any other local building codes or other codes that
may apply.
5. Do not use components other than those specified for use
with this unit.
6. Floor protection requirement must be followed precisely.
7. PL vent must be used for exhaust venting. Single wall vent is
not allowed. Follow PL vents manufacturer’s installation di-
rections and observe all listed clearances to combustibles.
WARNING
Do not install in a sleeping room.
Combustion air must come from the outside of the mobile home! Failure to do so may create negative
pressure within the mobile home and could disrupt proper venting and operation of the furnace.
The structural integrity of the floors, walls, ceiling and roof must be maintained.
Installation should be in accordance with manufactured home and safety standard (HUD), CFR 3280, part 24.
Figure 9
WARNING
Do not install in a sleeping room.
The structural integrity of the floors, walls, ceiling and roof must be
maintained.
Installation must follow clearances shown in figures 3, 4 and 5.
Installation must follow venting procedures outlined on pgs. 7, 8 and 9.
