BURN POT REMOVAL & INSTALLATION
ENDURANCE 50F BURN POT REMOVAL & INSTALLATION
Figure 16
Figure 17 Figure 18
The following is used for cleaning or replacement of burn pot.
Steps 1-5 cover the burn pot removal and steps 6-11 cover re-
moval of pot frame (not required for cleaning or maintenance).
Ensure the unit is allowed time to cool.
Positioning Parts for Removal
1. Enter maintenance mode from the Main menu
(Current Setting).
2. Select Auto Pot Removal.
3. Close all doors and press Enter.
4.Waitforpotpartstobepositionedforremoval.
5.Whencomplete,doorcanbeopenedandpartscan
be removed.
Remove Pot Parts
6. Begin by lifting upward on the Removable Ramp
(Figure 16).
7. Lift Cast Re-light Plate up and out (Figure 17).
CAUTION Pinch Point
Please take care to keep hands and other objects
out of the pot area during movement.
