16 ENDURANCE 50F CONTROL BOARD OPERATION
Fuel Type
1- High Ash
2-LWheat
3-Wheat
4- HM Corn
5- Corn
6- LM Corn
7- Cherry Pit
Up to 10 – will need to scroll
MENU=BACK ENTER=SELECT
Temp Control
Manual
T-Stat
Fuelmizer
MENU=BACK ENTER= SELECT
Ignition Mode
Auto
Manual
MENU=BACK ENTER= SELECT
Main Blower Speed
600 CFM Sw. Off
800 CFM Sw. Off
600 CFM
800 CFM
MENU=BACK ENTER= SELECT
Lvl 1 Auger Trim
Level 1 Slowest
Level 2
Level 3 Default
Level 4
Level 5 Fastes)
MENU=BACK ENTER= SELECT
Lvl 1 Draft Trim
Level 1 Slowest
Level 2
Level 3 Default
Level 4
Level 5 Fastest
MENU=BACK ENTER= SELECT
Maintenance Mode
Auto Pot Removal
Plate Control
Pusher Control
MENU=BACK ENTER= SELECT
Thermostat High
Heat Level 3
Heat Level 4
Heat Level 5
MENU=BACK ENTER= SELECT
If either thermostat
modes are selected
Current Settings
FuelType:10-PPellet
Control:Manual
Ignition:Auto
Blower:800CFM
AugerTrim:3
DraftTrim:3
Maintenance:(Selectableonlywhenunitisoff)
Init.PotChange:(Selectableonlyinrunningstatus)
ENTER = Change
ON = Start
NO VACUUM
PRESENT CHECK
DOORS
SELF CLEANING
IN PROGRESS
Clean Complete
Light 2 cups pellets with
gel and wait 3 minutes
*See Quick Start Guide
ENTER = Done
CONTROL BOARD OPERATION
Stabilizing
LEVEL 3
Fuel:10-PPellet
Vacuum Flame Auger
Running
LEVEL 3
Fuel:10-PPellet
Vacuum Flame Auger
CLOSE ALL
DOORS AND
PRESS ENTER
NO VACUUM
PRESENT
CHECK DOORS
COMPLETE
Remove components.
Clean and Reinstall.
MENU = BACK
Pusher Assembly
Hold up to extend.
Hold down to retract.
MENU = BACK
Top Plate
Hold up to extend.
Hold down to retract.
MENU = BACK
NOTE: When using Fuelmizer Mode, after 60
minutes with no call for heat the unit will shutdown
and restart when heat is again required.
NOTE: If front door is left open with door switch off enabled with fire in the furnace, the blower will turn back
on in 2 minutes if the fan limit control is warm enough for the blower to run.
Do not leave the furnace unattended with the door open.
NOTE: With door switch off enabled the main blower
will turn off while the front door is open. This is to help
to keep the dust from the Fire door and Ash pan blow-
ing during cleaning.
Igniting
LEVEL 3
Fuel:10-PPellet
Vacuum Flame Auger
Manual Ignite Auto Ignite
POSITIONING
PLEASE WAIT
CLOSE ALL
DOORS AND
PRESS ENTER
CLOSE ALL
DOORS AND
PRESS ENTER
NO VACUUM
PRESENT
CHECK DOORS
NO VACUUM
PRESENT
CHECK DOORS
