General view of product
EN
Ports Description
16V AC Port for the supply voltage (16 V alternating current)
+ Port for positive wires (top for components, bottom for
sensors and switches)
E1 - E8 Port for the negative wires of sensors and switches pro-
viding an input signal: Inputs 1 to 8
A1 - A8 Port for the negative wires of components receiving an
output signal: Outputs 1 to 8
P1 - P2 To set the period of time during which an output is
activated
DIP switch Description
1 - 4 Selection of programs
LEDs Description
A1 - A8 Indicates which output is working
Table 1: Operating elements
Potentiometer (Poti)
Angle of
rotation °
0° 35° 75° 105° 135° 175° 210° 260° 270°
Duration
in seconds
1 s 2 s 3 s 4 s 5 s 10 s 20 s 30 s 35 s
Table 2: Potentiometer (Poti)
You will find further explanations on the DIP switch and the poten-
tiometers in Chapter 8 »Interesting facts« of the present instruction
manual.
TIP
