Technical data
EN
9. Technical data
Power supply
Designation Value
Operating voltage 16 V AC
max. power consumption Traffic-Control 1500 mA
Output voltage Traffic-Control approx. 22 V DC
Output current Traffic-Control A1-A4 in total max. 650 mA
Output current Traffic-Control A5-A8 in total max. 650 mA
max. power consumption Traffic-Light-Control 800 mA
Output voltage Traffic-Light-Control A1-A2 approx. 22 V DC
Output current Traffic-Control A1-A2 in total max. 650 mA
Output current Traffic-Control per LED approx. 20 mA
Table 22: Power supply
Symbols
Symbol Meaning
Product is subject to the European
WEEE Directive
CE conformity label
RoHS
CE Conformity incl. RoHS directive
EMC
tested
CE Conformity incl. EMC directive
1:87/H0/16.5 mm track gauge
1:160/N/9 mm track gauge
X
Action
g
Note
Table 23: Symbols
