Connecting Traffic-Control/Traffic-Light-Control
EN
4. Connecting Traffic-Control/Traffic-Light-Control
The Traffic-Control and Traffic-Light-Control units operate on 16 V alter-
nating current.
The required alternating voltage can be generated by means of
FALLER 50 VA, 50 to 60 Hz transformer, Art. 180641, for instance.
TIP
Fig. 3: Connecting Traffic-Control/Traffic-Light-Control
X
Connect Traffic-Control/Traffic-Light-Control to 16 V alternating cur-
rent, see Fig. 3.
X
The Traffic-Control/Traffic-Light-Control unit is now connected to its
supply voltage.
