General view of product
EN
Ports Description
16V AC Port for the supply voltage (16 V alternating current)
+ Port for the positive wire of stop section/traffic lights
A1 Port for the stop sections for traffic lights 1
A2 Port for the stop sections for traffic lights 2
RT GE GN
Ampel 1
Port for traffic lights 1
RT GE GN
Ampel 2
Port for traffic lights 2
P1 To set the duration of the green phase at traffic lights 1
P2 To set the duration of the green phase at traffic lights 2
L1-L8 Ports for running lights (for example Art. 161830)
LEDs Description
A1 - A2 Indicates which output is working
Table 3: Operating elements
Potentiometer (Poti)
Angle
of rota-
tion °
0° 35° 75° 105° 135° 175° 210° 260° 270°
Dura-
tion in
seconds
1 s 2 s 3 s 4 s 5 s 10 s 20 s 30 s 35 s
Table 4: Potentiometer (Poti)
