9 9
HARD
-
MOUNT
4.3
ATTENTION!
Do not use the tool-access
holes found on the heel rest
as bolt-securing holes.
Required:
NOTE:
4x M8 bolts, 4x nuts,
and 10x washers are
required which are
not included.
Front Mounting Points
x4 x4
x4
x10
X mm
25 mm
(Max.)
M8x(25+X) mm
M8
