4 4
To get started with using the CSL Elite Pedals V2, decide on your preferred pedal
unit positions and if you will hard-mount the pedals to a surface. Connect the CSL
Elite Pedals V2 to your wheel base via the included RJ12 cable or to a PC via
USB. It is important to follow the chapter sequence of this manual for an e󰀨ective
assembly and setup procedure.
ATTENTION: See chapter 4.4 “Connections” for which type of add-on peripheral
devices must be connected to which port of the CSL Pedals. Only use the
included USB and RJ12 cables from your CSL Elite Pedals V2 package contents
to avoid damage!
ASSEMBLY & SETUP
PLAN YOUR SETUP
4
4.1
PEDAL MODULE ADJUSTMENT
4.2
Tools required for adjusting the pedal units:
13 mm
6 mm
4 mm
c1 c2 c3
