F&F LE-03MQ CT - Page 29

Register
address
(Dec/Hex)
Measuring parameter System
Description
Units
a
3P4W 3P3W 1P2W
0 / 00 L1 (L-N) Phase voltage V √ X √
2 / 02 L2 (L-N) Phase voltage V √ X X
4 / 04 L3 (L-N) Phase voltage V √ X X
6 / 06 L1 Current strength A √ √ √
8 / 08 L2 Current strength A √ √ X
10 / 0A L3 Current strength A √ √ X
12 / 0C L1 Active power
W √ X √
14 / 0E L2 Active power W √ X √
16 /10 L3 Active power W V X X
18 /12 L1 Apparent power VA V X V
20 / 14 L2 Apparent power VA V X X
22 / 16 L3 Apparent power VA V X X
24 / 18 L1 Reactive power Var V X V
26 / 1A L2 Reactive power Var V X X
28 / 1C L3 Reactive power Var V X X
30 / 1E L1 Power factor - V X V
32 / 20 L2 Power factor - V X X
34 / 22 L3 Power factor - V X X
36 / 24 L1 Phase angle Degrees V X V
38 / 26 L2 Phase angle Degrees V X X
40 / 28 L3 Phase angle Degrees V X X
42 / 2A
V V X X
46 / 2E Average line current A V V V
48 / 30 Sum of phase currents A V V V
52 / 34 Total system power W V V V
56 / 38 Total system volt amps VA V V V
60 / 3C Total system Var Var V V V
62 / 3E
Total system power factor (*1)
- V V V
66 / 42 Total system phase angle Degrees V V V
70 / 46
Frequency of supply voltages
Hz V V V
Average phase voltage
among phase and neutral wire
LE-03MQ CT - User manual
29
