242 / F2 Phase 2 current THD % V V X
244 / F4 Phase 3 current THD % V V X
248 / F8 % V X V
250 / FA % V V V
258 / 102 Phase 1 current demand A V V V
260 / 104 Phase 2 current demand A V V X
262 / 106 Phase 3 current demand A V V X
264 / 108
Maximum phase 1 current
demand
A V V V
266 / 10A
Maximum phase 2 current
demand
A V V X
268 / 10C
Maximum phase 3 current
demand
A V V X
334 / 14E % V V X
336 / 150 % V V X
338 / 152 % V V X
340 / 154 % V V X
342 / 156 Total active energy kWh V V V
344 / 158 Total reactive energy kVarh V V V
Notes:
1. The power factor has its sign adjusted to indicate the nature of the load. Positive for capacitive and
negative for inductive.
2. The power sum demand calculation is for import power only.
Average line to neutral volts THD
Average line current THD
Line 1 to line 2 volts THD
Line 2 to line 3 volts THD
Line 3 to line 1 volts THD
Average line to line volts THD
