9
Maintenance
Periodic cleaning of your new ceiling fan is the only
maintenance that is needed.
When cleaning, use only a soft brush or lint free cloth to
avoid scratching the finish.
Abrasive cleaning agents are not required and should be
avoided to prevent damage to finish.
CAUTION
Do not use water when cleaning your ceiling fan. It
could damage the motor or the blades and create the
possibility of electrical shock.
Operating Instructions - Pull Chain
Figure 1
Reversing
Switch
Speed Control
Pull Chain
1. Restore electrical power to the outlet box by turning the
electricity on at the main fuse box.
2. Check the operation of the fan by gently pulling on the
pull chain switch. (Figure 1)
3. If airflow is desired in the opposite direction, turn the
fan off and wait for the blades to stop turning. Then slide
the reverse switch to the opposite position and turn fan
on again. Your fan model is equipped with a 4-position,
3-speed, pull chain switch. The operating sequence is as
follows:
1st Pull = HIGH 3rd Pull = LOW
2nd Pull = MEDIUM 4th Pull = OFF
Figure 6
10. Assemble the Housing Switch Cup onto the assembled
Adapter with three screws. (Figure 6)
11. Restore Power and your fan is now wired to be turned
on and off from the fan pull chain speed control.
Assembling and Mounting the Fan Blades and Switch Hsg (Cont’d)
Blade Cleaning
Periodic light dusting of the blades is recommended.
A feather duster will work best.
Avoid using water, cleansers, or harsh rags, which can
warp and ruin the blades.
