Fantec TV-LHD - Connection with 2 Channel of Cinch Audio; Connection with Coaxial Output

FANTEC TV-LHD
7-3 Connection with 2 Channel of Cinch Audio
7-4 Connection with Coaxial output
25
Connect red and white audio (A/V) cable from FANTEC TV-LHD to the audio input jack of TV or
audio device.
When you have a multi channel decoder/amplifier with coaxial input, you can enjoy 5.1CH
high quality sound through coaxial cable. The illustration on the top shows how to connect
with coaxial cable
