11
fantech
DUCTING INSTALLATION EXAMPLES
Fully dedicated system Partially dedicated system
Simplified installation - Option 1
Simplified installation - Option 2
Bathroom
Fresh Air
Exhaust Air
Central Control - optional
Fresh air to living room
Exhaust CG 4 (4” Adjustable Grill)
FEL 4 (4” Miter Elbow)
460 mm
3m
HRV
Bedrooms
460 mm
Supply
Exhaust
Supply
Exhaust
