3 Installation
3.1 Use PoE or External Power Adapter
X3G, called as ‘the device’ hereafter, supports two power supply modes, power supply from external
power adapter and X3G supports 802.3af Class 2 Power over Ethernet (PoE) complied switch
PoE power supply saves the space and cost of providing the device additional power outlet. With a
PoE switch, the device can be powered through a single Ethernet cable which is also used for data
transmission. By attaching UPS system to PoE switch, the device can keep working at power outage
just like traditional PSTN telephone which is powered by the telephone line.
For users who do not have PoE equipment, the traditional power adaptor should be used. If the
device is connected to a PoE switch and power adapter at the same time, the power adapter will be
used in priority and will switch to PoE power supply at power failure on the power adapter.
Please use the power adapter supplied and the PoE switch met the specifications to ensure the
device worked properly.

Fanvil X3SP Specifications

General

Power over Ethernet (PoE)	Yes
Power consumption (typical)	1.2 W
Wi-Fi	No
Security algorithms	AES, MD5
Networking standards	IEEE 802.1x, IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	DHCP, PPPoE, L2TP, OpenVPN, SIP2.0 UDP/TCP/TLS, RTP/RTCP/SRTP, STUN, DHCP, PPPoE, 802.1x, L2TP, SNTP, FTP/TFTP, HTTP/HTTPS, TR069
Display diagonal	2.4 \
Display resolution	320 x 240 pixels
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
RJ-9 ports quantity	2
Lines quantity	2 lines
Call log entries	300
Phonebook capacity	500 entries
Number of VoIP accounts	-
Certification	CE, FCC 15 B, EN55022 B, EN61000-3-2, EN61000-3-3, EN55024, EN60950-1
Voice codecs	G.711a, G.711u, G.722, G.723.1, G.726
Frequency range	0 - 7 Hz
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 65 %
Volume control	Digital
Keypad number of keys	32
Number of function keys	5

Weight and Dimensions

Depth	174 mm
Width	159 mm
Height	171 mm
Package depth	62 mm
Package width	275 mm
Package height	215 mm
