User can add blocked number by entering the number in the edit box and click “Add” button. To
remove a number from the blocked list, select the number from the dropdown box and click “Delete”
button to remove it.
8.17 PHONE / Audio
Change the audio settings,
Table 5 - Audio Settings on Web
Parameters
Description
First Codec
The first preferential DSP
codec:G.711A/U,G.722,G.723,G.729,G.726-32,
ILBC,AMR,AMR-WB
Second Codec
The second preferential DSP codec:
G.711A/U,G.722,G.723,G.729,G.726-32,
ILBC,AMR,AMR-WB,NONE
Third Codec
The third preferential DSP codec:
G.711A/U,G.722,G.723,G.729,G.726-32 ,
ILBC,AMR,AMR-WB,NONE
Fourth Codec
The forth preferential DSP codec:
G.711A/U,G.722,G.723,G.729,G.726-32 ,
ILBC,AMR,AMR-WB,NONE
Fifth Codec
The fifth preferential DSP codec:
G.711A/U,G.722,G.723,G.729,G.726-32,
ILBC,AMR,AMR-WB,NONE
Sixth Codec
The sixth preferential DSP codec:
G.711A/U,G.722,G.723,G.729,G.726-32,
ILBC,AMR,AMR-WB,NONE
Onhook Time
Configure the least reflection time of Hand
down, the default is 200ms.
Tone Standard
Set the country standard of call progress tones,
including dial tone, busy tone, ring-back tone,
etc.

Fanvil X3SP Specifications

General

Power over Ethernet (PoE)	Yes
Power consumption (typical)	1.2 W
Wi-Fi	No
Security algorithms	AES, MD5
Networking standards	IEEE 802.1x, IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	DHCP, PPPoE, L2TP, OpenVPN, SIP2.0 UDP/TCP/TLS, RTP/RTCP/SRTP, STUN, DHCP, PPPoE, 802.1x, L2TP, SNTP, FTP/TFTP, HTTP/HTTPS, TR069
Display diagonal	2.4 \
Display resolution	320 x 240 pixels
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
RJ-9 ports quantity	2
Lines quantity	2 lines
Call log entries	300
Phonebook capacity	500 entries
Number of VoIP accounts	-
Certification	CE, FCC 15 B, EN55022 B, EN61000-3-2, EN61000-3-3, EN55024, EN60950-1
Voice codecs	G.711a, G.711u, G.722, G.723.1, G.726
Frequency range	0 - 7 Hz
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 65 %
Volume control	Digital
Keypad number of keys	32
Number of function keys	5

Weight and Dimensions

Depth	174 mm
Width	159 mm
Height	171 mm
Package depth	62 mm
Package width	275 mm
Package height	215 mm
