• A full operational test and a test for possible
leakages must be carried out by the tter after
installation.
• e exible hose shall be tted in such a
way that it cannot come into contact with a
moveable part ofthe housing unit and does
not pass through any space susceptible of
becoming congested.
• Grease cranes produced at the factory to meet
the requirement of all life hob.
POSITIONING
CLEARANCES
REQUIRED
WHEN FITTING
THE HOB WITH
A COOKER
HOOD ABOVE
• is appliance is to be built into a kitchen
unit or 600mm worktop,providing the
following minium distances are allowed;
• e edges of the hob must be a minimum
distance of 60 mm from a side or rear wall.
• 700 mm between the highest point of the
hob surface (including the burners) and the
underside of any horizontal surface directly
above it.
• 400 mm between the hob surfaces, providing
that the underside of the horizontal surface is
in line with the outer edge of the hob. If the
underside of the horizontal surface is lower
than 400 mm, then it must be at least 50 mm
away from the outer edges of the hob.
• 50 mm clearance around the appliance and
between the hob surface and any combustible
materials.
• You must have a gap of at least 25 mm and at
most 74 mm between the underneath of the
appliance and any surface that is below it.
