GAS ADJUSTMENT
• Take precautions on the operations
and adjustments to be carried out when
converting from one gas to another.
• All work must be carried out by a
qualied technician.
• Before you begin, turn o the gas and
electricity supply to the appliance.
1. Change the injector of the burners.
Remove the pan
support, Burner lid
and Flame spreader.
Unscrew the injector
using a 7mm box
spanner and replace
it with the stipulated
injector for new gas
supply. Carefully
reassemble the all
components.
After injectors are
replaced, it is advisable
to strongly tighten the
injector in place.
Injector
2 Adjustment of minimum level of the ame.
1. Turn the taps down to minimum.
2. Remove the knob from the tap and place
a small bladed screwdriver in the centre of
the tap shaft.
3. e correct adjustment is obtained when
the ame has a length of about 3 - 4 mm.
– For butane/ propane gas, the adjusting
screw must
– be tightly screwed in.
– Ret the control knob.
Make sure that the ame does not go out
by quickly turning from maximum ow to
minimum ow. If it does then remove the
control knob and make further adjustments
to the gas ow, testing it again once the
adjustment has been made.
4. Repeat this process for each one of the gas
taps.
Adjustment screw
Control
handle
Tap
Sealing ring
