96
SECTION 10 -- ENGINE -- CHAPTER 1
4. Disconnect the engine stop electromagnet
wire (1).
204
5. Remove the quick couplers (1) on the filter
and (2) on the injection pump, remove the injec-
tion pump supply pipe.
Remove the pipe (3) coming from the tank.
CAUTION
Make the vehicle safe and put the gear into neutral.
MIF1161A
205
6. Remove the quick couplers and pipe (1) installed
between the fuel filter and fuel pump.
206
To Next Page
