Farr 400UTV - Changing the Final Gear Oil

8-12
1CAUTION:
Be sure no foreign material enters the final
gear case.
4. Install the oil filler bolt, and then tighten it
to the specified torque.
Tightening torque:
Final gear oil filler bolt:
23 Nm (2.3 m·kgf, 16.3 ft·lbs)
Changing the Final Gear Oil
1. Place the vehicle on a level surface.
2. Place a container under the final gear
case to collect the used oil.
3. Remove the oil filler bolt and the drain
bolt to drain the oil.
1. Final gear oil drain bolt
4. Install the drain bolt, and then tighten it to
the specified torque.
Tightening torque:
Final gear oil drain bolt:
20 Nm (2.0 m·kgf, 14 ft·lbs )
5. Add the recommended final gear oil up to
the brim of the filler hole.
