Farr 400UTV - Cleaning the Engine Air Filter Elements

8-20
Tightening torque:
Spark plug:
17.5 Nm(1.75 m·kgf, 12.4 ft·lbs)
NOTE:
If a torque wrench is not available when you
are installing the spark plug, a good estimate
of the correct torque is 1/4 to 1/2 turn past
finger tight. Have the spark plug tightened
to the specified torque as soon as possible.
4. Install the spark plug cap.
5. Lower the cargo bed.
Cleaning the Engine Air Filter
Element
NOTE:
There is a check hose at the bottom of the air
filter case. If dust or water collects in this
hose, empty the hose and clean the air filter
element and air filter case.
1. Air filter check hose
1. Remove the seats. (See pages 4-16 ─
4-17 for seat removal and installation
procedure.)
2. Remove the Engine cover. (See page 8-9
for Engine cover removal and installation
procedure.)
3. Remove the connecting rubber tube
between air cleaner and throttle valve
