2-3
Chapter 2: Motherboard information
Connectors/Jumpers/Slots
Page
1.
ClearRTCRAM(3-pinCLRTC1) 2-8
2.
DDR3LSO-DIMMmemoryslot 2-6
3.
PCIex1slot --
4.
LVDS/EDPconnector(30-pinLVDSEDP) 2-14
5.
BIOSprogrammingheaderforAaeon(8-pinSPI1) 2-14
6.
Audioamplieranddigitalaudioconnector(10-pinSPDIF_AMP) 2-16
7.
USB3.0connectors(10-pinUSB3_1,USB3_3) 2-15
8.
LVDSpanelvoltageselection(10-pinLVDS_CTL) 2-9
9.
Backlightinverterpowerconnectors(10-pinINV1,6-pinINV2) 2-17
10.
DigitalI/Oconnector(10-pinDIO) 2-14
11.
Frontpanelaudioconnector(10-pinAAFP) 2-12
12.
Serialportconnectors(10-pinCOM2,COM34) 2-16
13.
Systempanelconnector(10-pinF_PANEL1) 2-13
14.
SIMcardconnector(10-pinSIM1) 2-11
15.
CameraSerialInterfaceconnector(31-pinCSI1) 2-17
16.
MainandstandbypowerLEDs(LED1,LED2) 2-1
17.
SerialATA6.0Gb/sconnector(7-pinSATA6G1) 2-13
18.
SATApowerconnector(4-pinSATA_PWR1) 2-12
19.
COM1RI/+5V/+12Vselection(6-pinCOM1_V1) 2-9
20.
12VDCpowerconnector(2-pinDC_PWR) 2-11
21.
MiniPCIex1slot(MINI_CARD1) 2-15
22.
M.2E-keyconnector(2230_M2E) 2-18
23.
InternalPOELANconnectors(2-pinJL1,JL2) 2-11
24.
Batteryconnector(2-pinBATTERY1) 2-18
25.
IntegratedIntel
®
processor 2-6
