3.3.2 CPUConguration
The items in this menu show CPU-related information.
Intel Virtualization Technology [Enabled]
[Enabled] Allows a hardware platform to run multiple operating systems
separately and simultaneously, enabling one system to
virtually function as several systems.
[Disabled] Disables this function.
Power Limit 1 Enable [Enabled]
Allows you to enable or disable Power Limit 1. Conguration options: [Enabled]
[Disabled]
Power Limit 1 Clamp Mode [Enabled]
Allows you to enable or disable Power Limit 1 Clamp Mode. Conguration options:
[Enabled] [Disabled]
Power Limit 1 Power [Auto]
Allows you to set Power Limit 1 in watts. When Auto is selected, Power Limit 1 is
decided by the default silicon support value. Conguration options: [Auto] [6] ~ [25]
Power Limit 1 Time Window [Auto]
Allows you to set Power Limit 1 Time Window in seconds. When Auto is selected,
Power Limit 1 Time Window is decided by the default silicon support value.
Conguration options: [Auto] [1] [2] [3] [4] [5] [6] [7] [8] [10] [12] [14] [16] [20] [24]
[28] [32] [40] [48] [56] [64] [80] [96] [112] [128]
3.3.3 SATAConguration
While entering Setup, the BIOS automatically detects the presence of SATA
devices. The SATA Port items show Not Installed if no SATA device is installed to
the corresponding SATA port.
Chipset SATA [Enable]
Allows you to enable or disable the chipset SATA controller. Conguration options:
[Enable] [Disable]
3.3.4 USBConguration
The USB Devices item lists auto-detected values. If no USB device is detected,
the item shows None.
Legacy USB Support [Enabled]
[Enabled] Enables the support for USB devices on legacy operating
systems (OS).
[Disabled] USB devices are only available when running BIOS Setup.
