2.4 Central Processing Unit (CPU)
ThismotherboardcomeswithanintegratedIntel
®
processor.
2.5 System memory
ThismotherboardcomeswithoneDoubleDataRate3LowVoltage(DDR3L)
SmallOutlineDualInlineMemoryModule(SO-DIMM)socket.Thegureillustrates
thelocationoftheDDR3LDIMMsocket:
FAY-003
FAY-003 CPU onboard
Integrated Intel
®
processor
(Bottom)
FAY-003
FAY-003 204-pin DDR3L DIMM socket
DIMM_A1
