3-7
Chapter 3: BIOS setup
3.3.8 DigitalIOPortConguration
The items listed in this screen congure Digital IO settings.
DIO Port1~Port4 [Output], DIO Port5~Port8 [Input]
Conguration options: [Input] [Output]
The following item appears only when you set DIO Port1~8 to [Output].
Output Level [High]
Conguration options: [High] [Low]
3.4 Chipset menu
The Chipset menu items allow you to change conguration options for the North
Bridge and South Bridge.
North Bridge
Primary Display [IGD]
Allows you to decide which graphics controller to use as the primary boot device.
Conguration options: [IGD] [PCIe]
Primary IGFX Boot Display [Auto]
Select the video device which will be activated during POST. This setting has
no effect if an external graphics device is present. The secondary boot display
selection appears based on your selection and the VGA mode is supported only on
primary display. Conguration options: [Auto] [HDMI] [eDP/LVDS] [DP]
LVDS Panel Support [Enabled]
Enables or disables LVDS panel support. Conguration options: [Disabled]
[Enabled]
LVDS Color Depth [Auto]
Select the color depth of the LCD panel to be used as display. Conguration
options: [Auto] [24-bit] [18-bit]
LVDS Channel Type [Auto]
Select the channel type of the LCD panel to be used as display. Conguration
options: [Auto] [Single] [Dual]
LVDS Brightness Type [Normal]
Allows you to select the LVDS brightness type. Conguration options: [Normal]
[Inverted]
