Faytech FAY-003 - Hardware Monitor; SIO Configuration

3-5
Chapter 3: BIOS setup
[Auto] Allows the system to detect the presence of USB devices
at startup. If detected, the USB controller legacy mode is
enabled. If no USB device is detected, the legacy USB support
is disabled.
3.3.5 Hardware Monitor
This menu displays the system/CPU temperatures and power status.
3.3.6 SIOConguration
The items in this menu allow you to congure Super IO settings.
[*Active*] Serial Port 1
Use this device [Enabled]
Allows you to enable or disable this logical device. Conguration options:
[Enabled] [Disabled]
The following two items appear only when you set Use this device to
[Enabled].
Possible [Use Automatic Settings]
Allows you to select an optimal setting for Super I/O devices. Conguration
options: [Use Automatic Settings] [IO=3F8h; IRQ=4;] [IO=2F8h; IRQ=12]
Mode [RS232]
Allows you to select the Serial Port mode. Conguration options: [RS232]
[RS422] [RS485]
[*Active*] Serial Port 2
Use this device [Enabled]
Allows you to enable or disable this logical device. Conguration options:
[Enabled] [Disabled]
Possible [Use Automatic Settings]
This item appears only when you set Use this device to [Enabled] and
allows you to select an optimal setting for Super I/O devices. Conguration
options: [Use Automatic Settings] [IO=2F8h; IRQ=12] [IO=3F8h; IRQ=4;]
[*Active*] Serial Port 3
Use this device [Enabled]
Allows you to enable or disable this logical device. Conguration options:
[Enabled] [Disabled]
