37X INSTALLATION & OPERATION MANUAL
372/373 MODELS
9
4.7 Connecting to Water Supply
Water pipe connections and fixtures directly connected to a potable water supply shall be sized, installed, and maintained
in accordance with federal, state, and local codes.
Connect water line adapter to the bulkhead fitting labeled “WATER” or “H2O” on the back of the dispenser. The water
supply line connected to the bulkhead fitting should be a minimum 3/8" ID or larger if required by local codes. Before
installing, flush several gallons of water through a newly fabricated line to remove any debris. Installing a shutoff valve near
the connection will be helpful when removing the dispenser.
Do not turn on the water supply at this time.
Note: According to the National Sanitation Foundation (NSF), an ASSE 1022 approved backflow prevention device must
be installed on the water supply line before connecting to the dispenser. If needed, one can be purchased from FBD under
part number 12-2272-0001. The backflow device must have a line connected to the vent that diverts any flow to a drain.
Failure to divert flow can result in water overflow.
Bulkhead Fittings
Fitting Label Description
H2O
WATER
Water supply connection.
CO2 Carbon dioxide supply connection (for standard congurations).
N2 Nitrogen supply connection (for nitrogen congurations).
MAIN GAS
Connection for gas driving pumps, active charge system, and pneumatic faceplate
(where applicable) on universal and multi-gas congurations.
Can be compressed air, CO or N.
GAS 1
Connection for gas being injected into product (for universal and multi-gas
congurations). Can be CO or N. Gas 1 supplies both barrels unless Gas 2 also exists.
GAS 2
Connection for gas being injected into product (for universal and multi-gas
congurations). Can be CO or N. Gas 2 serves barrel 2 if present.
SYRUP RIGHT
SYRUP LEFT
SYR X*
Base syrup connection. The base avor syrup in a given barrel. When SYRUP LEFT is
used, it designates syrup for barrel 1. When SYRUP RIGHT is used, it designates syrup for
barrel 2.
FLAV X*
Flavor shot connection. The avor shot that will be mixed with a base syrup (on multi-
avor dispensers only).
SYRUP 4
SYRUP 3
CO
2
H
2
O
SYRUP 2
SYRUP 1
Artwork for 24-2403-0001_D
LABEL, BULKHEAD DIAGRAM, 774
Created 01/27/17 (Rev D), ECN 17-095
*Contact FBD Engineering Department for digital artwork files of layout with color specifications.
PANTONE BLACK C BRUSHED SILVER
SYRUP 4
SYRUP 3
CO
2
H
2
O
SYRUP 2
SYRUP 1
Artwork for 24-2403-0001_D
LABEL, BULKHEAD DIAGRAM, 774
Created 01/27/17 (Rev D), ECN 17-095
*Contact FBD Engineering Department for digital artwork files of layout with color specifications.
PANTONE BLACK C BRUSHED SILVER
SYRUP 4
SYRUP 3
CO
2
H
2
O
SYRUP 2
SYRUP 1
Artwork for 24-2403-0001_D
LABEL, BULKHEAD DIAGRAM, 774
Created 01/27/17 (Rev D), ECN 17-095
*Contact FBD Engineering Department for digital artwork files of layout with color specifications.
PANTONE BLACK C BRUSHED SILVER
SYRUP 4
SYRUP 3
CO
2
H
2
O
SYRUP 2
SYRUP 1
Artwork for 24-2403-0001_D
LABEL, BULKHEAD DIAGRAM, 774
Created 01/27/17 (Rev D), ECN 17-095
*Contact FBD Engineering Department for digital artwork files of layout with color specifications.
PANTONE BLACK C BRUSHED SILVER
SYRUP 4
SYRUP 3
CO
2
H
2
O
SYRUP 2
SYRUP 1
Artwork for 24-2403-0001_D
LABEL, BULKHEAD DIAGRAM, 774
Created 01/27/17 (Rev D), ECN 17-095
*Contact FBD Engineering Department for digital artwork files of layout with color specifications.
PANTONE BLACK C BRUSHED SILVER
SYRUP 4
SYRUP 3
CO
2
H
2
O
SYRUP 2
SYRUP 1
Artwork for 24-2403-0001_D
LABEL, BULKHEAD DIAGRAM, 774
Created 01/27/17 (Rev D), ECN 17-095
*Contact FBD Engineering Department for digital artwork files of layout with color specifications.
PANTONE BLACK C BRUSHED SILVER
SYRUP 4
SYRUP 3
CO
2
H
2
O
SYRUP 2
SYRUP 1
Artwork for 24-2403-0001_D
LABEL, BULKHEAD DIAGRAM, 774
Created 01/27/17 (Rev D), ECN 17-095
*Contact FBD Engineering Department for digital artwork files of layout with color specifications.
PANTONE BLACK C BRUSHED SILVER
SYRUP 4
SYRUP 3
CO
2
H
2
O
SYRUP 2
SYRUP 1
Artwork for 24-2403-0001_D
LABEL, BULKHEAD DIAGRAM, 774
Created 01/27/17 (Rev D), ECN 17-095
*Contact FBD Engineering Department for digital artwork files of layout with color specifications.
PANTONE BLACK C BRUSHED SILVER
SYRUP 4
SYRUP 3
CO
2
H
2
O
SYRUP 2
SYRUP 1
Artwork for 24-2403-0001_D
LABEL, BULKHEAD DIAGRAM, 774
Created 01/27/17 (Rev D), ECN 17-095
*Contact FBD Engineering Department for digital artwork files of layout with color specifications.
PANTONE BLACK C BRUSHED SILVER
SYRUP 4
SYRUP 3
CO
2
H
2
O
SYRUP 2
SYRUP 1
Artwork for 24-2403-0001_D
LABEL, BULKHEAD DIAGRAM, 774
Created 01/27/17 (Rev D), ECN 17-095
*Contact FBD Engineering Department for digital artwork files of layout with color specifications.
PANTONE BLACK C BRUSHED SILVER
* “X” represents the barrel number for syrup (SYR) connections, and the flavor number for FLAV connections.
