37X INSTALLATION & OPERATION MANUAL
372/373 MODELS
5
2. SPECIFICATIONS AND REQUIREMENTS
2.1 General Requirements
2.2 Electrical Requirements
‡
2.3 Dimension and Weight Specifications
* All pressure values are listed in the manual in gauge pressure.
†
Reference dispenser nameplate label to identify refrigerant type.
‡
General requirements only. Always check dispenser nameplate label for specific rating information.
Requirement
Syrup Supply Pressure 70 - 72 PSI* (483 - 496 kPa)
Water Supply Pressure
30 PSI (207 kPa) Minimum Flowing Pressure
70 PSI (483 kPa) Maximum Static Pressure
Gas Supply Pressure 70 - 72 PSI (483 - 496 kPa)
Clearance 3” (76 mm) Sides and Back, 12” (305 mm) Top
Refrigerant
†
R404A OR R448-A
Requirement
Frequency 60 Hz 50 Hz
Operational Voltage 230 VAC ± 10% 230 VAC ± 10%
Current 20 A 20 A
Minimum AMP Breaker 20 20
Specications 372 372 MFLV 373
Width 15.8” (400 mm) 15.8" (400 mm) 20.1” (511 mm)
Depth 25.2” (640 mm) 25.2" (640 mm) 25.2” (640 mm)
Height - Short Door 31.5” (800 mm) 31.5" (800 mm) 31.5” (800 mm)
Height - Tall Door 37.7” (958 mm) N/A N/A
Weight - Empty 196 lb (89 kg) 199 lb (90 kg) 215 lb (98 kg)
Weight - Operational 212 lb (96 kg) 217 lb (98 kg) 239 lb (108 kg)
Weight - Shipping 228 lb (103 kg) 233 lb (106 kg) 304 lb (138 kg)
