FBD 372 - Page 61

37X INSTALLATION & OPERATION MANUAL
372/373 MODELS
59
Figure 11.12 Electrical Diagram for 372 Multi-Flavor Dispenser
3 OF 3
3.3 VDC
ADA KEYPAD
TANK 2SYR 2
ANA-GND
RETURN TEMP
GAS 1
GAS 2
SYR 1 H2O FLAVOR 2
FLAVOR 1
FLAVOR 3FLAVOR 4TANK 1MAIN GAS
5VDC VOLTAGE
OUTPUT
OUTPUT
Harness Functions 372
TANK 1
■
TANK 2
■
SYR 1
■
SYR 2
■
REG CO2/GAS 1
■
H2O
■
UNREG CO2/MAIN GAS
■
ACTIVE CHARGE (DCC)
■
