DIGITAL MERCHANDISER
56X/77X MODELS
18
7.7 Updating Images and Videos on Multiple-Barrel Merchandisers
All multiple-barrel merchandisers have a USB port to allow new content to be added. The process below describes the
procedure for accessing the USB ports.
1. Tilt the merchandiser up so that the back panel is accessible.
2. Remove the two screws securing the L-shaped panel (Figure 7.5). The panel should hinge open.
3. Remove the USB and replace it with a USB containing updated content or add the desired content to the existing
USB and reinsert it (Figure 7.6).
4. Close the access panel and tighten the screws.
5. Tilt the merchandiser down so the screen is visible. Unlock the screen and reboot the door.
6. For the four-barrel merchandiser, make sure you select the “Update Cards” button to upload any new flavor images
to the door.
Figure 7.5
Figure 7.6
7.8 Adding Content to a USB Drive
The process below describes the procedure to add content to a new USB drive. Ensure all folders are named as described.
If any folder names are different than illustrated below, the content will not load into the merchandiser properly.
1. Create two new folders on the USB drive. Rename the two folders flavors and
videos using lowercase letters only (Figure 7.7).
2. Add videos to the video folder. Though the merchandiser supports videos in
.mp4, .mov, and .mpeg format, .mp4 is the best format to use.
3. Add flavor images to the flavors folder. Though the merchandiser supports
images in .png, .jpg, and .bmp format, .png is the best format to use.
Figure 7.7
