DIGITAL MERCHANDISER
56X/77X MODELS
3
2. SPECIFICATIONS
2.1 General Requirements
The digital merchandiser is compatible with only dispensers from either the 56x or 77x series. The merchandiser will not
function properly if installed onto a dispenser outside of the 56x or 77x series. The barrel count on the dispenser and the
merchandiser must match. For example, a three-barrel merchandiser should only be installed on a three-barrel dispenser.
2.2 Dimension, Weight, and Resolution Specifications
561 Merchandiser
Width 17 in. (432 mm)
Depth 2.9 in. (74 mm)
Height 26 in. (660 mm)
Weight 32.1 lb (14.6 kg)
Shipping Weight 39.1 lb (17.7 kg)
Video Viewing Area
1080 x 1280
.mp4
Flavor Background
1080 x 640
.png
Flavor Images
(1X Base Flavor,
4X Flavor Add-ins)
600 x 500
.png
Two-Barrel Merchandiser
Width 17 in. (432 mm)
Depth 2.9 in. (74 mm)
Height 26 in. (660 mm)
Weight 30.4 lb (13.8 kg)
Shipping Weight 37.4 lb (17 kg)
Video Viewing Area
1080 x 1280
.mp4
Flavor Card (x2)
516 x 600
.png
Three-Barrel Merchandiser
Width 20.3 in. (516 mm)
Depth 2.9 in. (74 mm)
Height 26 in. (660 mm)
Weight 33.2 lb (15.1 kg)
Shipping Weight 40.7 lb (18.5 kg)
Video Viewing Area
1080 x 1540
.mp4
Flavor Card (x3)
340 x 340
.png
Four-Barrel Merchandiser
Width 27.1 in. (688 mm)
Depth 2.9 in. (74 mm)
Height 26 in. (660 mm)
Weight 42.5 lb (19.3 kg)
Shipping Weight 50.7 lb (23 kg)
27” Screen for Video
1920 x 1080
.mp4
8” Screen for Flavor
Card (x4)
600 x 800
.png
