DIGITAL MERCHANDISER
56X/77X MODELS
26
(continued from previous page)
Condition Possible Causes How to Fix
Screen is Completely Black
No output or backlight ever coming on
screen.
Power is o or not
making it to the door.
1. Open the access panel on the back of the door and
look for power indicator lights.
2. There is a slot in the back top of the door. If power
is confirmed, the display could have been turned o.
The power button can be pressed through the access
slot.
3. Check the door power harness (white 2-pin Molex
connector on the right side of the door) and verify
that wire routing and end connections are not faulty
or somehow disconnected. Use an ohmmeter to
verify continuity in the wire(s) and/or a multimeter to
measure 12VDC across the wires for power.
Display is turned o. Use switch to turn display ON.
Flavor card is incorrect for the flavor in
the barrel.
The flavor card image
needs to be changed.
See Section 7.5.
To Next Page
