ST100 Series HART
12 Fluid Components International LLC
HART COMM NUMB. HART COMMAND DESCRIPTION HART DATA TYPE & SIZE
12
READ USER MESSAGE DEV. ID NUMB.
BITSTRING (12 BYTES)
13
READ TAG TAG
ASCII BIT STRING (6 BYTES)
READ DESCRIPTOR DESCRIPTOR
ASCII BIT STRING (12 BYTES)
READ DATE CODE DATE
ASCII BIT STRING (5 BYTES)
14
READ PV SENSOR INFO
SENSOR SERIAL NUMBER SENSOR S/N
UNSIGNED-24
LIMITS UNITS CODE - PV LIMITS UNITS CODES
ENUM (1BYTE)
UPPER SENSOR LIMIT - PV UPPER SENSOR LIMIT
FLOAT (4 BYTES)
LOWER SENSOR LIMIT - PV LOWER SENS LIMITS
FLOAT (4 BYTES)
MIN SPAN - PV MIN SPAN
FLOAT (4 BYTES)
15
READ OUTPUT INFORMATION
ALARM SELECT CODE ALRM SEL. CODE
ENUM (1BYTE)
TRANSFER FUNCTION CODE TRN. FUNC. CODE
CHAR (1BYTE)
FLOW RANGE UNITS CODE RNG UNITS CODE
CHAR (1BYTE)
FLOW UPPER-RANGE VAL UP RANG VALUE
FLOAT (4 BYTES)
FLOW LOWER-RANGE VAL LO RANG VALUE
FLOAT (4 BYTES)
FLOW DAMPING VALUE DAMPING VALUE
FLOAT (4 BYTES)
WRITE PROTECT CODE W PROTECT CODE
ENUM (1BYTE)
RESERVED (SET TO 250) RESERVED
ENUM (1BYTE)
16
READ FINAL ASSEMBLY NUMBER
ASSEMBLY NUMBER ASSEMB. #
UNSIGNED-24
17
WRITE MESSAGE
MESSAGE BITSTRING (24 BYTES)
