ST100 Series HART
Fluid Components International LLC 33
BIT MEANING CLASS DEVICE STATUS BITS SET
0 Ethernet Communication Failure Hardware 4
1 USB Communications Failure Hardware 4
2 Industrial Communication Protocol Fail Hardware 4
3 Procees Temperature Over Max Limit Hardware 4
4 Process Temperature Under Min Limit Hardware 4
5 Flow Sensor Heater #1 Shorted Hardware 4
6 Flow Sensor # 2 Shorted Hardware 4
7 Flow Sensor #1 Open Hardware 4
Status Byte 2
BIT MEANING CLASS DEVICE STATUS BITS SET
0 Flow Sensor Heater #2 Open Hardware 4
1
Flow Sensor A/D Counts Exceed Max
Limit
Hardware 4
2 Flow Sensor A/D Counts Under Min Limit Hardware 4
3 Flow Sensor Signal Exceeds 120% Limit Hardware 4
4 Flow Sensor Signal Exceeds 100% Signal Hardware 4
5 Flow Sensor Signal Exceeds A/D Limit Hardware 4
6 FE Component Error – AD56 27 Hardware 4
7 FE Component Error – TMP100 Hardware 4
Status Byte 3
BIT MEANING CLASS DEVICE STATUS BITS SET
0 FE Component Error – AD5754 Hardware 4
1 FE Component Error – ACT/REF Sensor A/D Hardware 4
2 FE Component Error – Current Sensors A/D Hardware 4
3
FE Component Error – GRND Ret & Pressure
Sensor A/D
Hardware 4
4 FE Component Error – Heaters I Sensors A/D Hardware 4
5 FE Component Error ARM7 Undefined Fault Hardware 4
6 FE Component Error ARM7 SWI Fault Hardware 4
7
FE Component Error ARM7 Prefetch Abort
Faule
Hardware 4
Status Byte 4
