ST100 Series Probus PA
Pressure Analog Input (AI) Block
The instruments equipped with a pressure sensor will make use of the Pressure AI block. This block gets its input from the Pressure transducer Block.
REL. INDEX PARAMETER SLOT INDEX DATA TYPE (LENGTH) STORE SIZE READ/WRITE
1 ST_REV 3 17 UNSIGNED16 N 2 R
2 TAG_DESC 3 18 OCTETSTRING S 32 RW
3 STRATEGY 3 19 UNSIGNED16 S 2 RW
4 ALERT_KEY 3 20 UNSIGNED 8 S 1 RW
5 TARGET_MODE 3 21 UNSIGNED 8 S 1 RW
6 MODE_BLK 3 22 DS-37 S 3 R
7 ALARM_SUM 3 23 DS-42 D 8 R
8 BATCH 3 24 DS-67 S 10 RW
10 OUT (PRESS.) 3 26 DS-33 D 5 R
11 PV_SCALE 3 27 FLOAT S 8 R/W
12 OUT_SCALE 3 28 DS36 S 11 R/W
13 LIN_TYPE 3 29 UNSIGNED 8 S 1 R/W
14 CHANNEL 3 30 UNSIGNED16 S 2 R/W
16 PV_FTIME 3 32 FLOAT S 4 R/W
17 FSAFE_TYPE 3 33 UNSIGNED 8 S 1 R/W
18 FSAFE_VALUE 3
34 FLOAT S 4 R/W
19 ALARM_HYS 3 35 FLOAT S 4 R/W
21 HI_HI_LIM 3 37 FLOAT S 4 R/W
23 HI_LIM 3 39 FLOAT S 4 R/W
25 LO_LIM 3 41 FLOAT S 4 R/W
27 LO_LO_LIM 3 43 FLOAT S 4 R/W
30 HI_HI_ALM 3 46 DS-39 D 16 R
31 HI_ALM 3 47 DS-39 D 16 R
32 LO_ALM 3 48 DS-39 D 16 R
33 LO_LO_ALM 3 49 DS-39 D 16 R
34 SIMULATE 3 50 DS50 S 6 R/W
35 OUT_UNIT_TEXT 3 51 OCTETSTRING S 16 R/W
Fluid Components International LLC
