ST100 Series Probus PA
24 Fluid Components International LLC
ST100 PROFIBUS PA (CLASSIC) DIAGNOSIS TABLE
PROFIBUS PA
DIAG_EXT
PROFIBUS PA Classic
DIAG (*2)
ST100 FCI Error or Status Description FCI Fault Type
# 3-5 DIA_MEASUREMENT (Any) FE reports ABOVE_dR_MAX_FAULT NF
# 3-6 FCI RESERVED (Not used) NF
# 3-7 DIA_TEMP_ELECTR (Any) FE reports TMP100_ADC_FAULT NF
# 4-0 DIA_HW_ELECTR (Any) FE reports AD5754_DAC_FAULT F
# 4-1 FCI RESERVED (Not used) NF
# 4-2 DIA_HW_ELECTR (Any) FE reports CURR_SENSORS_ADC_FAULT NF
# 4-3 DIA_HW_ELECTR (Any) FE reports HTRS_PRESSNS_ADC_FAULT NF
# 4-4 DIA_MEASUREMENT (Any) FE reports HTRS_FAULTS_ADC_FAULT F
# 4-5 DIA_HW_ELECTR (Any) FE reports FE_ARM7_UNDEFINE_FAULT NF
# 4-6 DIA_HW_ELECTR (Any) FE reports FE_ARM7_SWI_FAULT NF
# 4-7 DIA_HW_ELECTR (Any) FE reports FE_ARM7_PREFETCH_ABORT_FAULT NF
# 5-0 DIA_HW_ELECTR (Any) FE reports FE_ARM7_DATA_ABORT_FAULT NF
# 5-1 DIA_HW_ELECTR (Any) FE reports FE_ARM7_FIQ_FAULT NF
# 5-2 DIA_HW_ELECTR (Any) FE reports FE_ARM7_SPURIOUS_INT_FAULT NF
# 5-3
FCI RESERVED (Not used) *** Currently not implemented. CORE: pro-
cess data not updated because (all) FE's in self-test
NF
